GANG TYPE CNC LATHE

GT72

GT is a gang type slant bed CNC lathe

Techical Data

CAPACITY

Swing Over Cross Bed

Φ400mm

Swing Over Cross Carriage

Φ100mm

Turning Length

250mm

Turning Diameter

Bar Materials up to Φ71mm

Single Workpiece up to Φ380mm

Bed Type

30° Slant Bed

TRAVELS

Z Axis

250mm

X Axis

800mm

Guideway Type

32mm THK/NSK ball screw rod

35mm THK/INA linear guideway

Z/X Axis

Up to 25m/min

Machining Accuracy

±0.0025mm

Surface roughness

≤Ra 1.6μm

SPINDLE

Spindle Nose Taper

A2-8

Speed

3000 RPM

Spindle Motor Power

11 kW Servo Motor

15 kW Servo Drive

Clamp

Hydraulic Collet

Spindle bore

Φ86mm

TOOLS

Tool type

Gang Type

Tool holder

Parting Tool Holders (2 Sets)

Single Tool Holders (2 Sets)

Dual Tool Holder (1 Set)

Drilling Tool Holders (3 Sets)

Motor & Servo

Z&X Axis

1.3 kW Servo Motor

1.5 kW Servo Drive

CNC CONTROL

Controller

SYNTEC

POWER SUPPLY

Total Power

15.5KW

Voltage

380VAC 50Hz

DIMENSIONS

Dimensions (L/W/H)

2229mm*1565mm*1767mm

Weight

2600 kg
Features

  • The patented slant bed design increases the X-axis travel to 800mm and Z-axis to 250mm reducing the lathe size and stability.

  • With turning, drilling, tapping, and contouring functions can reduce cycle processing and improve production efficiency.

  • Each spindle bearing assembly was tested for dynamic balance before installation to ensure high-speed running stability.

  • Equips with 32mm ball screw rod rail and 35mm linear guideway to provide precision and low vibration tool carriage movement.

  • Equips with auto lubrication system to ensure transmission system smoothly and long-lived.

  • SYNTEC CNC system co-works with quality electrical parts providing a rapid-operation and durable use.
Optional
Oil Bar Feeder
Servo Bar Feeder
Chain Chip Conveyor
Part Catcher
Oil Mist Collector
Fanuc CNC Syetem
3 Jaw Hydraulic Chuck

Application

Competent to handle the turning process with brass, bronze, aluminum, steel, stainless steel, and rigid plastic with bars diameter up to Φ71 mm or single workpieces up to Φ350mm. High Rigidity casting iron body provides the possibility of higher hardness materials and better smoothness (smaller roughness).
